1.用途：適用于鋼板水平吊裝，工字鋼及型鋼的吊裝。
2.采用首鋼低碳合金鋼制造。
3.載荷范圍：0-8噸。
4.以兩只試驗為額定載荷，吊裝作業時兩只或四只配套使用，四只作業時須與平衡梁配套使用，可自動脫勾。
5.吊裝過程中不得碰撞被吊物，嚴禁超載使用。
6.試驗載荷=額定載荷×2。
7.額定載荷指吊鉗成對使用，吊點夾角為60°時允許起吊的zui大重量。
8.頭部滾輪設計，能避免鋼繩損壞；接觸面積大，穩定性好。
9.吊鉗尖角呈銳三角形，方便插入狹小空間。
起重鉗|辰力吊索具
LIFTING CLAMPS|CHENLI RIGGING
QS型雙板起重鉗
產品詳情
Application：Horizontal，I beam steel or shape steel lifting of steel plate.
Loading range：0 to 8ton.
Two pieces of clamp are used for the testing，but 2 pieces or 4 pieces are recommended for lifting operation.Balance beam is needed，otherwise，it will cause automatic unloading.
Tested load is 2 times of working load.
The rated loading is the maximum weight as the angle is 60 degree and a pair of clamps are recommended.
The head rolls a design，can avoid a steel rope hurting，getting in touch with area is large，the stability is better.
The point presents triangle，be convenient to get into narrow and small space.
產品介紹
