1.用途：適用于鋼板水平吊裝、豎直吊裝和型鋼的翻轉。
2.采用首鋼低碳合金鋼制造。
3.適于H鋼翻轉(由H狀一|狀，|狀一H狀)。
4.載荷范圍：0-10噸。
5.以單只試驗為額定載荷，吊裝作業時單只使用，水平吊裝時須加平衡梁。
6.吊裝過程中不得碰撞被吊物，嚴禁超載使用。
7.試驗載荷=額定載荷 x 2。
8.強韌耐久，易操 作。
起重鉗|辰力吊索具
LIFTING CLAMPS|CHENLI RIGGING
DFQ型翻轉鉗
產品詳情
1.Application：Horizontal vertical or reversal of steel plate.
2.Material：Low carbon alloy steel.
3.The most suitable for H steel to reversal(from H shape to | shape and from | shape to H shape).
4.Loading range：0 to 10 ton.
5.One piece of clamp is used for the testing，and one piece is recommended for lifting operation，balance beam is needed for horizontal lifting.
6.The loaded object shall not touch anything when operating，over loading is prohibited.
7.Tested load is 2 times of working load.
8.Durable enduring，easy operation.
產品介紹
