1.用途：適用于鋼板水平吊裝。
2.采用首鋼低碳合金鋼制造。
3.載荷范圍：0-10噸。
4.以兩只試驗為額定載荷，吊裝作業時2只或4只配套使用，鋼板較大時加平衡梁。
5.試驗載荷=額定載荷×2。
6.帶彈簧鎖無作業狀態下，索具自然加緊，吊上物體夾力成比例增加。
7.嚴禁超載使用，不得碰撞被吊物。
8.強韌耐久，易操 作。
起重鉗|辰力吊索具
LIFTING CLAMPS|CHENLI RIGGING
PDB型橫吊起重鉗
產品詳情
1.Application：Horizontal lifting of steel plate.
2.Material：Low carbon alloy steel.
3.Loading range：0 to 10 ton.
4.Two pieces of clamp are used for the testing，but 2 pieces or 4 pieces are recommended for lifting operation，balance beam is needed for big size steel plate.
5.Tested load is 2 times of working load.
6.With lock spring during the clamp non-work condition，locking device going in nature step-up，put the object in the clamp，the strength becomes the proportion enhancement.
7.The loaded object shall not touch anything when operating，over loading is prohibited.
8.Durable enduring，easy operation.
產品介紹
