我們公司新產品--X系列手扳葫蘆，較普通產品具有以下特點：
1.空載時利用離合彈簧使鏈條可自由拉動，精密鑄鋼手輪帶三角形限位凸點，作業時避免葫蘆鏈條下降到底部時，預防重物自由滑落的an全隱患；
2.左右墻板配置整體軸承，起重鏈輪為整體軸承形式配合，運轉靈活，手拉力暢快輕盈；
3.內部齒輪傳動件均采用合金鋼和嚴格的滲碳熱處理工藝，相比傳統工藝增加了齒輪的抗耐磨性；
4.沖壓式導鏈板，使鏈條導向更順暢，防護效果更佳；
5.采用高 強度G80辰力專 利鏈條。
Our company’s latest products.X Series lever block. Comparedwith common products，they have the following characteristis.
1. Use the clutch spring to make the lifting chain free to pull when no load，precision cast steel hand wheel with triangular limit bump，avoid the safety hazard of the lifting chain dropping to the bottom and the heavy object sliding down freely during operation；
2. The left and right wall plates are equipped with integral bearings，and the lifting sprocket is in the form of integral bearings to match，so that the operation is flexible and the hand pull is smooth and light；
3. The internal gear transmission parts are all made of 20CrMnTi alloy steel and strict carburizing heat treatment process，which increases the wear resistance of the gears compared with the traditional process；
4. The stamping type chain guide plate makes the chain guide more smoothly and the protection effect is better；
5. Use high strength T8 European standard lifting chain.
