1.用途：適用于鋼板水平吊裝。
2.采用低碳合金鋼制造或鍛造分兩種。
3.載荷范圍：0-8噸。
4.以兩只試驗為額定載荷，吊裝作業(yè)時四只配套使用，須與平衡梁配套使用，可自動脫勾。
5.吊裝過程中不得碰撞被吊物，嚴禁過載使用。
6.試驗載荷=額定載荷×2。
7.額定載荷指吊鉗成對使用，吊點夾角為60°時允許起吊的zui大重量。
8.強韌持久，易操 作。
起重鉗|辰力吊索具
LIFTING CLAMPS|CHENLI RIGGING
PDQ型單板起重鉗
產(chǎn)品詳情
1.Application：Horizontal lifting of steel plate.
2.Material：Low carbon alloy steel.
3.Loading range：0 to 8 ton.
4.Two pieces of clamp are used for the testing，but 4 pieces are recommended for lifting operation. Balance beam is needed，otherwise，it will cause automatic unloading.
5.The loading object shall not touch anything when operating，over loading is prohibited.
6.Tested load is 2 times of working load.
7.The rated loading is the maximun weight as the angle is 60 degress and a pair of clamps are recommended.
8.Durable enduring，easy operation.
產(chǎn)品介紹
