1.用于：適用于鋼板水平吊裝、豎直吊裝和型鋼的翻轉。
2.采用合金鋼鍛造，載荷更重。
3.適于H鋼和其他型鋼(H、I、L、T型)的翻轉。
4.載荷范圍：0-5噸。
5.以單只試驗為額定載荷，吊裝作業時單只使用，水平吊裝時，須加平衡梁。
6.吊裝過程中不得碰撞被吊物，嚴禁超載使用。
7.試驗載荷=額定載荷×2。
8.強韌耐久，易操 作。
起重鉗|辰力吊索具
LIFTING CLAMPS|CHENLI RIGGING
DFM型模鍛翻轉鉗
產品詳情
1.Application：Horizontal or vertical reversal lifting of steel plate and other products.
2.Material：Low carbon alloy steel precision forging，the load is heavier.
3.The most suitable for H steel and H.I.LT steel to reversal.
4.Loading range：0 to 5 ton.
5.One piece of clamp is used for the testing，and one piece is recommended for lifting operation balance beam is needed for horizontal lifting.
6.The loaded object shall not touch anything when operating，over loading is prohibited.
7.Tested load is 2 times of working load.
8.Durable enduring，easy operation.
產品介紹
